A note about PIC MCU’s

July 24th, 2008 | Categories: Electronics | Tags:
Leave a comment

Since I couldn’t see a cross reference list about PIC MCU’s between the 10F 16F 18F and 18F(80TQFP), I’ve decided to list it here in all it’s glory. I’ll add to it ass I use more MCU’s

MCLR/VPP VSS(GND) VDD(+) PGD/ICSPDAT PGC/ICSPCLK
PIC10FXXX PDIP Pin 8 Pin 7 Pin 2 Pin 5 Pin 4
PIC16FXXX PDIP Pin 4 Pin 20 Pin 1 Pin 19 Pin 18
PIC18FXXX 40-PDIP Pin 1 Pin 12 Pin 11 Pin 40 Pin 39
PIC18F 80-TQFN Pin 9 Pin 11,31,51,70 Pin 12,32,48,71 Pin 47 Pin 52
PIC18F 68-PLCC Pin 16 Pin 68,19,36,53 Pin 20,37,49,2 Pin 48 Pin 54
PICKIT 2 Programmer Pin 1 Pin 3 Pin 2 Pin 4 Pin 5
